Using Jest for React screenshot testing

3 min read 1067

Jest and Reach Logos for Screenshot Testing

A screenshot test is a comparison of screenshots between the older UI of an app and the new UI. The difference between the two is usually highlighted with red, like so:

Screenshot Test

Notice that one of the screenshots above failed the test because there were 6414 differing pixels due to the color change of the text.

There is probably no other way to inspect visual regressions today because all other tests inspect only the code and not the image displayed in the browser.

That being said, the two most popular Jest screenshot testing libs for React today are jest-image-snapshot and react-screenshot-test.

jest-image-snapshot vs. react-screenshot-test

Here’s a short introduction to both of these tests and a side-by-side comparison:

Jest vs React Screenshot Testing Comparison

Both libs are capable of taking screenshots by using Puppeteer, a Node.js library that provides a high-level API to control headless Chrome or Chromium over the DevTools Protocol, but jest-image-snapshot can work with other screenshot tools as well.

jest-image-snapshot requires Puppeteer configuration on the app side, whereas react-screenshot-test encapsulates the entire process, providing its own API for screenshot testing.

Now let’s dive into setup and usage detail differences.

We made a custom demo for .
No really. Click here to check it out.

Installation

First, jest-image-snapshot, react-screenshot-test, and Puppeteer should be installed to begin local testing:

npm i jest-image-snapshot puppeteer

or

npm i react-screenshot-test puppeteer

Setup

Setting up jest-image-snapshot boils down to adding one extra method to the Jest expect:

// setupTests.js

import { toMatchImageSnapshot } from "jest-image-snapshot";
expect.extend({ toMatchImageSnapshot });

On the other hand, the react-screenshot-test configuration lives in the jest.screenshot.config.js file:

// jest.screenshot.config.js

module.exports = {
  testEnvironment: "node",
  globalSetup: "react-screenshot-test/global-setup",
  globalTeardown: "react-screenshot-test/global-teardown",
  testMatch: ["**/?(*.)+(screenshot).[jt]s?(x)"],
  transform: {
    "^.+\\.[t|j]sx?$": "babel-jest", // or ts-jest
    "^.+\\.module\\.css$": "react-screenshot-test/css-modules-transform",
    "^.+\\.css$": "react-screenshot-test/css-transform",
    "^.+\\.scss$": "react-screenshot-test/sass-transform",
    "^.+\\.(jpg|jpeg|png|gif|eot|otf|webp|svg|ttf|woff|woff2|mp4|webm|wav|mp3|m4a|aac|oga)$":
      "react-screenshot-test/asset-transform"
  },
  transformIgnorePatterns: ["node_modules/.+\\.js"]
};

It should be paired with babel.config.js:

// babel.config.js

module.exports = {
  presets: ["babel-preset-react-app"]
};

The react-screenshot-test lib requires more configuration because it builds parts of the React app for testing purposes but doesn’t use the build script of react-scripts. This approach allows testing components of the app in isolation, just like regular Jest snapshot testing.

jest-image-snapshot and react-screenshot-test examples

A jest-image-snapshot test looks as follows:

// src/screenshot.test.js

import puppeteer from 'puppeteer'

it('main page screenshot test', async () => {
    const browser = await puppeteer.launch({});
    const page = await browser.newPage();
    await page.goto('http://localhost:5000');

    const image = await page.screenshot();
    expect(image).toMatchImageSnapshot();
    await browser.close();
});

The code above is a standard Puppeteer workflow. It will launch a browser, open the page, navigate, and finally, take a screenshot.

The only line of code that is test related is from the setup section: expect(image).toMatchImageSnapshot().

This line of test code is responsible for difference detection and different image generation — or a new screenshot generation in case there wasn’t a screenshot taken previously.

Let’s now take a look at react-screenshot-test, which has its own minimal and convenient API for testing. Here is a typical test:

// src/index.screenshot.js

import React from "react";
import { ReactScreenshotTest } from "react-screenshot-test";
import "./index.css";
import App from "./index";

ReactScreenshotTest.create("App")
    .viewport("Desktop", {
        width: 1024,
        height: 768
    })
    .viewport("iPhone X", {
        width: 375,
        height: 812,
        deviceScaleFactor: 3,
        isMobile: true,
        hasTouch: true,
        isLandscape: false
    })
    .shoot("main page", <App />)
    .run();

The benefits of this approach can be easily seen in an example with a large amount of states possible, such as button styles and sizes or responsive rendering for all of the breakpoints.

For example, for all button styles in one place:

ReactScreenshotTest.create("Buttons")
    .viewport("Desktop", {
        width: 1024,
        height: 768
    })
    .shoot("primary", <Button type="primary" />)
    .shoot("secondary", <Button type="secondary" />)
    .shoot("ghost", <Button type="info" />)
    .shoot("danger", <Button type="danger" />)
    .shoot("warning", <Button type="warning" />)
    .run();

For five breakpoints in one place:

ReactScreenshotTest.create("Header")
    .viewport("XS", {
        width: 365,
        height: 768
    })
    .viewport("S", {
        width: 768,
        height: 768
    })
    .viewport("M", {
        width: 1024,
        height: 768
    })
    .viewport("L", {
        width: 1200,
        height: 768
    })
    .viewport("XL", {
        width: 1600,
        height: 768
    })
    .shoot("responsive", <Header />)
    .run();

Running tests locally

jest-image-snapshot needs the app to be served using some web server, such as using the “serve” package before screenshot tests can be run. This can be achieved locally using two console windows, one for the server and the other for testing or alternatively using the convenience package start-server-and-test.

Minimal package.json for the jest-image-snapshot should look like this:

{
  "dependencies": {
    "jest-image-snapshot": "latest",
    "puppeteer": "latest",
    "react": "latest",
    "react-dom": "latest",
    "react-scripts": "latest",
    "serve": "latest",
    "start-server-and-test": "latest"
  },
  "scripts": {
    "build": "react-scripts build",
    "serve": "serve -s build",
    "test": "react-scripts test",
    "test:jest-image-snapshot": "npm run build && start-server-and-test serve http://localhost:5000 test"
  }
}

According to the package.json above, the only command that needs to be executed for screenshot tests is:

npm run test:jest-image-snapshot

Now, for react-screenshot-test minimal package.json:

{
  "dependencies": {
    "puppeteer": "latest",
    "react": "latest",
    "react-dom": "latest",
    "react-screenshot-test": "latest"
  },
  "scripts": {
    "test:react-screenshot-test": "SCREENSHOT_MODE=local jest -c jest.screenshot.config.js"
  }
}

Notice that package.json is short. Only one command needs to be executed for running the tests:

npm run test:react-screenshot-test

Summary

There is no clear winner in the libs comparison: both react-screenshot-test and jest-image-snapshot add value using their own approach.

Using jest-image-snapshot package would be a great choice if you already use or plan to use Puppeteer on the project for e2e tests (e.g., checking text on the page, clicking on buttons, etc).

The gold standard for testing by Kent C. Dodds is applied perfectly here: “The more your tests resemble the way your software is used, the more confidence they can give you.”

On the other hand, react-screenshot-test package’s value is the ease of pairing every single component in the app with a screenshot of how the component should look with various options and screen resolutions in a single test.

If it’s difficult to decide on which lib to use, keep in mind that they both can work just fine together. In fact, here’s a CI workflow example (and source code for the demo project):

// .github/workflows/screenshot-tests.yml

name: Screenshot Tests

on:
    pull_request:
        branches:
            - main

jobs:
    screenshot:
        name: Main Page
        runs-on: ubuntu-16.04
        timeout-minutes: 5
        steps:
            - uses: actions/[email protected]

            - name: Use Node.js
              uses: actions/[email protected]
              with:
                  node-version: "12"

            - name: Install Dependencies
              run: yarn

            - name: Jest Image Snapshot
              run: npm run test:jest-image-snapshot

            - name: React Screenshot Test
              run: npm run test:react-screenshot-test

React Screenshot Test

Happy testing!
